Volkswagen Polo Service & Repair Manual: Blender
Blender was developed for hassle-free two-part clear coat
and top coat touch-up. |
Applies well to all base surfaces |
Blends well with the old paint |
Keep the filler surface as small as possible. |
Paint filler spot thoroughly with water-based base paint
(overlapping spray applications) |
|
|
|
Touch-Up System for Two-Part Clear Lacquers |
Mixing ratio for two-part clear coat: |
Adjust the two-part clear coat according to technical
application information. Refer to
→ Chapter „Clear Coats“. |
|
|
|
– |
Paint over the water-based base paint with adjusted clear
coat (overlapping spray applications). |
|
|
|
– |
Apply pure Blender -LVE 013 100 A2- onto the touch-up area
inside the sanded surface. |
|
|
|
Touch-Up System for Two-Part Top Coats |
Mixing ratio for two-part top coat: |
Adjust the two-part top coat according to technical
application information. Refer to
→ Chapter „Top Coats“. |
|
|
|
– |
Paint over filler area thoroughly (overlapping spray
applications). |
|
|
|
– |
Apply pure Blender -LVE 013 100 A2- onto the touch-up area
inside the sanded surface. |
|
|
|
Polishing the Touch-Up Zones |
Air dry at +20 °C (68 °F) room temperature: |
Polish the touch-up areas after they have dried overnight |
|
|
|
Final drying time with forced drying is a minimum of 5 to 10
minutes. |
|
|
|
Forced drying is at +60 °C (140 °F) object temperature for
30 minutes. |
– |
After that, allow the touch-up areas to cool off for an hour
and polish at +20 °C (68 °F) room temperature. |
|
|
|
Final drying time for IR drying is a minimum of 5 to 10
minutes. |
|
|
|
IR dry with a short-wave radiator for 10 minutes |
– |
After that, allow the touch-up areas to cool off for an hour
and polish at +20 °C (68 °F) room temperature. |
Note
Polish the touch-up area with fine polishing paste by hand
or with a polishing machine. |
To finish, treat the surface with high-gloss sealant. |
|
|
|
Personal Protective Equipment: |
Note the safety data sheets |
Wear the personal protective equipment during application |
|
|
|
Flashpoint: |
+20 °C (68 °F) |
The guaranteed shelf life of 60 months from date of
manufacture. Use no later than the date indicated on the label
and store in original container at +20 °C (68 °F). |
|
|
|
Definition:
Two-Part HS Performance Clear Coat -LZK 769 K06 A5-
Edition 08/2012
Product Description
...
